New to UK Dreeft – Brake Wheels

Dreeft – Brake Wheels

1st intuitive braking system for manual wheelchairs

Inspired by Dutch bicycles, the Dreeft wheels incorporate a “back-pedal” braking system at their centre, enabling wheelchair users to activate a brake by lightly pulling the handrail backwards.

With Dreeft, you can slow down, turn and reverse without any friction in your hand and with 5x less effort! #dreeftwheels #dreeftbrakingwheels #dreeftwheelsinuk #dreeftwheelsuk #susurro

Manufacturer’s warranty: 2 years, excluding worn parts.

• SPOKES 24 spokes 14G black stainless steel

• TIRE 24" Schwalbe Marathon +

• HANDRAIL TYPE Black anodised aluminium Ø19 mm or Tetra Grip 24" handrail

• RIM TYPE Double-walled, black powder-coated aluminum

• GRIP FOR HANDRAIL Adhesive grip for MC Ø30 mm Tetra Grip 24” handrail

Wheel Dimensions	24" | 54 cm
Diameter of Handrail Screw Holes	Ø513 mm
Axis Diameter	12 mm 12.7 mm
Handrail Spacing	12 mm 19 mm
Maximum User Weight	120 kg | 136 lbs
Weight With Handrail	3 kg
Removable Grip Weight for Handrail	650 g
Axis Weight	99 g 123.5 g

** Axle Pins & Adapter

AXLE PINS

To adapt Dreeft to the wheelchair, you must obtain axles of the correct length.

You must measure the diameter and depth of the wheelchair's axles.

To do this, take both measurements from the diagram shown.

L: Measure the distance between the bearing and the start of the balls.

All axles have an adjustable range of +/- 2mm in length.

The original wheelchair wheel axles are likely not suitable.
